Display Part:
Display Screen 55” TFT with LED backlight
Display Ratio 16:9
Color 16.77M colors
Display area 1209.6*680.4mm
Resolution 1920*1080
Brightness 450cd/m2
Contrast 3000:1
View Angle 89/89/89/89 (L/R/U/D)
Screen Response Time Less than 8ms
Life time Over 50,000hrs
Android main board Part:
CPU Quad core RK3288
RAM DDR3 4G
Storage Flash memory 32G
Main Board Industrial board
Graphic Card Integrated graphics card
Network Card 10/100M/1000M adaptive card
WIFI Support WIFI
OS Android OS 8.1 and above
Interface Part:
USB USB2.0*2,
COM COM*1
HDMI Output HDMI*1
MIC Audio Input MIC Audio*1
Line Audio Output Line*1
Network RJ45*1
IR touch Parts:
Touch Type Infra-red
Points 10 points
Glass cover Tempered glass cover
Response Time Less than 5ms
Resolution 32767 * 32767
Position Accuracy ±1.5mm
Communication USB2.0
Life Time Over 60,000,000 touches
Support Parts:
Digital signage software: FREE
Warranty： One year warranty for free, extend the warranty by 7% for three years
